Contactor 12V JLG 3740013
JLG 3740013 fits to aerial work platforms 80HX, 110HX, and etc.
| Shape of the contactor | round shape 5 |
|---|---|
| Maximum length of the contactor L1 (mm) | 88 |
| Maximum width of the contactor W1 (mm) | 56 |
| Maximum height of the contactor H1 (mm) | 67 |
| Maximum diameter of the contactor D1 (mm) | 46 |
| Number of solenoids | 1 |
| Voltage of the solenoid (V) | 12 |
| Type of current | direct current |
| Resistance of the solenoid (Ohm) | 15.3 |
| Number of connections on the solenoid | 2 |
| Type of connection on the solenoid | stud |
| Number of contact connections | 2 |
| Type of contact connection | outer thread |
| Outer thread size | 5/16 |
| Type of outer thread | UNF |
| Pitch inch of outer thread | 24 |
| Right or left handed outer thread | right hand outer thread |
| Fuse present | NO |
| External diode present | NO |
| External resistor present | NO |
| Number of normal open contacts (NO) | 1 |
| Auxiliary contact present | NO |
| Magnetic blow outs present | NO |
| Top cover | closed |
| Shortest center distance between mounting holes C1 (mm) | 54 |
| Shape mounting surface | flat |
| Support present | NO |
