Contactor 48V JLG 7013303
€53.36 Excl. VAT
Contactor 48V JLG 7013303 fits JLG 3369E, JLG 3969E, JLG 45E and others.
| Shape of the contactor | square shape 1 |
|---|---|
| Maximum length of the contactor L1 (mm) | 61 |
| Maximum width of the contactor W1 (mm) | 52 |
| Maximum height of the contactor H1 (mm) | 122 |
| Number of solenoids | 1 |
| Voltage of the solenoid (V) | 48 |
| Type of current | direct current |
| Current (A) | 150 |
| Resistance of the solenoid (Ohm) | 100.8 |
| Number of connections on the solenoid | 4 |
| Type of connection on the solenoid | blade 6,3mm |
| Number of contact connections | 2 |
| Type of contact connection | outer thread |
| Outer thread size | M8 |
| Pitch metric of outer thread (mm) | 1.25 |
| Right or left handed outer thread | right hand outer thread |
| Fuse present | NO |
| External diode present | NO |
| External resistor present | NO |
| Number of normal open contacts (NO) | 1 |
| Auxiliary contact present | NO |
| Magnetic blow outs present | YES |
| Top cover | closed |
| Shortest center distance between mounting holes C1 (mm) | 16 |
| Longest center distance between mounting holes C2 (mm) | 25.4 |
| Number of closed holes | 10 |
| Shape mounting surface | flat |
| Support present | NO |
| Weight (kg) | 0.68 |
|---|
Description
A wide range of electrical components suitable for construction equipment. Reliable and genuine electrical components for JLG: connector plugs, contact elements including the JLG 7013303 , electric motors, electronic cards, emergency stops, fuses, footswitches, indicator lights, potentiometers, relays, sensors, switches.
Should you require any further information, feel free to give a shout and we will be glad to assist you!
