Hydraulic pump Genie 54222
€226.66 Excl. VAT
Hydraulic pump Genie 54222 fits GENIE Z45-22RT, Z45-25JRT
| Type of pump | gearpump |
|---|---|
| Number of elements | 1 |
| Type of flange | type B |
| Center distance of mounting holes C1 (mm) | 106 |
| Total length of pump L1 (mm) | 134 |
| Neck diameter D2 (mm) | 82.5 |
| Type of shaft | type D |
| Distance from flange to end L2 (mm) | 31 |
| Diameter of shaft D3 (mm) | 15.2 |
| Number of splines | 9 |
| Direction of rotation | clockwise |
| Position of suction port 1st element, only for pump type T POS-CO1 | side |
| Type of connections suction port1st element, only for pump type T TY-COa | type E |
| Thread type suction side of 1st element TA-Pa | 1 1/16 UNF |
| Position of pressure 1st element, only for pump type T POS-CO2 | side |
| Type of connections pressure 1st element, only for pump type T TY-COb | type E |
| Thread type pressure side of 1st element TA-Pb | 7/8 UNF |
| Flow control valve present | NO |
| Material of the housing | aluminium |
Description
Genie genuine, high-quality, and reliable hydraulic parts: Cylinders, electrical actuators, hydraulic motors, pumps including Genie54222, valve. A full line of hydraulic parts.
Good price, quick delivery, and secure payment. Can’t find a spare part or should you require any further information, feel free to give a shout and we will be glad to assist you!
Additional information
| Weight | 3.45 kg |
|---|---|
| Manufacturer / Brand |
