Hydraulic pump Genie 55940

563.33 Excl. VAT

Hydraulic pump Genie 55940.

Type of pump gearpump
Number of elements 2
Type of flange type A
Diameter of flange mounting holes D1 (mm) 11
Center distance of mounting holes C1 (mm) 106.4
Total length of pump L1 (mm) 196
Neck diameter D2 (mm) 82.5
Type of shaft type D
Distance from flange to end L2 (mm) 31.5
Diameter of shaft D3 (mm) 15.2
Number of splines 9
Direction of rotation clockwise
Position of suction port 1st element, only for pump type T POS-CO1 side
Type of connections suction port1st element, only for pump type T TY-COa type E
Thread type suction side of 1st element TA-Pa 1 1/16 UNF
Position of pressure 1st element, only for pump type T POS-CO2 side
Type of connections pressure 1st element, only for pump type T TY-COb type E
Thread type pressure side of 1st element TA-Pb 3/4 UNF
Position of suction port 2nd element, only for pump type T POS-CO3 side
Type of connections suction port 2nd element, only for pump type T TY-COc type E
Thread type suction side of 2nd element TA-Pc 1 1/16 UNF
Position of pressure port 2nd element, only for pump type T POS-CO4 side
Type of connections pressure port 2nd element, only for pump type T TY-COd type E
Thread type pressure side of 2nd element TA-Pd 3/4 UNF
Flow control valve present NO
Material of the housing aluminium

Description

Genie genuine, high-quality, and reliable hydraulic parts: cylinders, electrical actuators, hydraulic motors, pumps including Genie 55940, valves.

Good price, quick delivery, and secure payment. Can’t find a spare part or should you require any further information, feel free to give a shout and we will be glad to assist you!

Additional information

Weight 5.3 kg
