BUZZER HAULOTTE 2901011450 FIT TO OPTIMUM 8 / OPTIMUM 1930E, OPTIMUM 6 / OPTIMUM 1530E, COMPACT 8W / COMPACT 2247E, COMPACT 8 / COMPACT 2032E, COMPACT 14 / COMPACT 3947E, COMPACT 12 / COMPACT 3347E, COMPACT 10N / COMPACT 2632E, COMPACT 10 / COMPACT 2747E.

Type of buzzer:buzzer
Voltage (V):3-20
Nominal voltage (V):12
Volume dB:95
Tone:continuous
Number of connections:2
Type of connections:wires with connector
Type of sound:beep
Broadband sound:NO
Volume adjustment:not adjustable
Tone frequency (Hz):2800
Shape:round
Type of mounting:panel mount
Total width buzzer W1 (mm):14.5
Maximum diameter buzzer D1 (mm):42
Total number of holes:4
Number of round holes:4
Diameter of the (biggest) holes D3 (mm):2.8
Center distance: horizontal – length C1 (mm):50
Length of the wires (mm):330
Material of the housing:plastic
Light present:NO
Sticker present:NO
Support present:YES
Minimum current (A):0.01
Minimum voltage (V):3
Maximum voltage (V):20
CE-approved:NO
UL-approved:NO
SAE-approved:NO
Restriction of hazardous substances:NO
E-approved:NO
Minimum operating temperature (°C):-20
Maximum operating temperature (°C):70
