The Genie 87295 Hydraulic Steering Cylinder is designed to deliver precise and dependable steering control in hydraulic-driven lift and chassis systems. This steering cylinder converts hydraulic pressure into controlled linear motion, supporting smooth maneuverability and accurate directional response during equipment operation.
Built with a Type U base and a tube featuring an inner thread, this hydraulic cylinder is engineered for secure mounting and stable performance under demanding jobsite conditions. The cylinder body features a tube diameter (D3) of 60 mm, providing the strength required to handle continuous hydraulic pressure and operational stress.
The piston shaft assembly uses a piston head–clevis design, allowing effective force transfer and consistent movement. Key shaft dimensions include a shaft diameter (D4) of 25 mm and a secondary diameter (D5) of 25.5 mm, ensuring proper alignment and durability. The cylinder includes a piston stroke of 320 mm, enabling sufficient steering range for responsive equipment handling.
Additional dimensional specifications include a base diameter (D2) of 25.3 mm with a base length (L2) of 28.8 mm, a shaft length (L3) of 29 mm, and an overall extended length (L5) of 591 mm. These precise measurements support accurate fitment and reliable integration into compatible Genie steering systems.
Ideal for maintenance, repair, or hydraulic system replacement, the Genie 87295 Hydraulic Cylinder helps restore steering performance, minimize downtime, and extend the operational life of your equipment.
