HYDRAULIC MOTOR HAULOTTE 2431203520

HYDRAULIC MOTOR HAULOTTE 2431203520

Type of hydraulic motor: on the top
Length L1 (mm): 383
Length L2 (mm): 62
Type of flange TY-Fl: type C
Neck diameter D2 (mm):125
Number of mounting holes AT-GA:4
Diameter D3 (mm): 14
Centre distance C (mm): 113
Type of shaft TY-AS:type E
Distance L3 (mm): 114.5
Shaft diameter D4 (mm):40
Key width B (mm): 12
Thread type TA2: M30
Pitch metric Pm2 (mm):2
Number of connections: 4
Thread type TA3: 3/4 BSP
Pitch imperial Pi3: 14
Second thread type TA4: 3/8
Pitch imperial Pi4: 19
Mounting thread type TA5: M10
Pitch metric Pm5 (mm):1.5
