HYDRAULIC PUMP HAULOTTE 2505001950

HYDRAULIC PUMP HAULOTTE 2505001950

Type of pump:plunger pump
Number of elements:1
Type of flange:type B
Center distance of mounting holes C1 (mm):146
Total length of pump L1 (mm):289
Neck diameter D2 (mm):101.6
Type of shaft:type E
Distance from flange to end L2 (mm):42
Diameter of shaft D3 (mm):21.7
Number of splines:13
Thread type (on shaft) TA2:1/4 UNC
Direction of rotation:clockwise
Thread type of connections suction 1st element:M12
Center distance between mounting holes C-CO1a (mm):42.9
Center distance between mounting holes C-CO2a (mm):77.8
Thread type of connection pressure port 1st element TA-COb:M10
Center distance between mounting holes C-CO1b (mm):26.2
Center distance between mounting holes C-CO2b (mm):52.4
Flow control valve present:NO
Material of the housing:metal
