SWITCH GENIE 128202GT

SWITCH GENIE 128202GT.

Number of connections:6
Type of the connection:screw step
Current (A):10
Minimum voltage U1 (V):125
Maximum voltage U2 (V):277
Actuator present:YES
Type of the actuator:round
Length of the actuator L1 (mm):17
Built-in diameter D1 (mm):12
Length thread panelmount L3 (mm):10
Thread size TA1:15/32
Pitch (inch):32
Right or left handed thread:right-handed
Total length of the toggle switch L4 (mm):34
Total width of the toggle switch W2 (mm):22.5
Total height of the toggle switch H1 (mm):63.5
Sort of switch:double pole
Type of the switch:(on)-off-(on)
Material of the housing:metal-plastic
Material of the actuator:metal
IP value/protection:IP67
Cap present:YES
Symbol present:no
Light present:no
