SWITCH HAULOTTE 2901015790

SWITCH HAULOTTE 2901015790

Number of connections:3
Type of the connection:connector-blade 6,3mm
Current (A):16
Minimum voltage (V):12
Number of pins:4
Built-in length of the rocker switch L1 (mm):44
Built-in width of the rocker switch W1 (mm):22
Built-in height of the rocker switch H1 (mm):47
Number of actuators:1
Button present:YES
Material of the button:plastic
Material of the housing:plastic
IP value, dust- and water-resistance grade:IP53
Protection cap present:NO
Symbol present:option
Light present:yes
Colour of the light:clear
Voltage of the light (V) (V):12
Function:universal
Type of position of the first actuator:2F
Type of switch of the first actuator:2102A1
Number of poles in the switch:1
Weight (kg):0.032
