SWITCH MANITOU 673401

SWITCH MANITOU 673401

Type of pressure switch:sensor
Electronical:YES
Total Length L1 (mm):84.5
Largest outer diameter D1 (mm):27
Diameter D2 (mm):0.5
Length thread L2 (mm):9
Sort thread:outer thread
Thread size:1/4
Type of thread:BSP
Pitch imperial:19
Right or left handed thread:right-handed
Unit of the thread:imperial
Width across flats metric (mm):27
Type of connection:connector
Number of connectors:1
Maximum pressure BAR (Bar):350
Maximum pressure PSI (psi):5076320
Pressure adjustable:NO
Type contact:multiple,different or with signal
Minimum voltage input (V):10
Maximum voltage input (V):30
Minimum voltage output (V):0.5
Maximum voltage output (V):5.5
Remark:350 bar 10-30 VDC SIGNAL 0,5-5,5 V
