SWITCH SNORKEL 3020081

SWITCH SNORKEL 3020081

Number of connections:6
Type of the connection:screw step
Current (A):10
Minimum voltage U1 (V):125
Maximum voltage U2 (V):250
Actuator present:YES
Type of the actuator:round
Length of the actuator L1 (mm):16
Built-in diameter D1 (mm):12
Length thread panelmount L3 (mm):11
Thread size TA1:M12
Pitch (metric) (mm):0.8
Right or left handed thread:right-handed
Total length of the toggle switch L4 (mm):33.5
Total width of the toggle switch W2 (mm):22.7
Total height of the toggle switch H1 (mm):64
Sort of switch:double pole
Type of the switch:on-none-(on)
Material of the housing:metal-plastic
Material of the actuator:metal
Cap present:NO
Symbol present:no
Light present:no
