TRACTION WHEEL GENIE 1288762

TRACTION WHEEL GENIE 1288762

Sort of traction wheel SRT-WH:standard traction wheel
Diameter of the wheel D1 (mm):381
Width of the wheel W1 (mm):127
Diameter of the rim D2 (mm):318
Width of the rim W2 (mm):129
Shaft diameter D8 (mm):185
Inner offset of the flange OFF-IN (mm):76
Outer offset of the flange OFF-OUT (mm):38
Thickness of the flange TH-FL (mm):11.98
Material of the wheel (grouped) MAT-WH:rubber
Wheel material detail MAT-DET:rubber non-marking
Shape of the tread SH-TRED:cylindrical
Wheel profile PROF-WH:other
Material of the rim MAT-RIM:cast iron
Groove for seal ring present SEAL-PR:NO
Cam present CAM-PR:NO
Number of bolt holes QTY-BO:5
Type of bolt hole TY-BO:cylindrical
Diameter of the bolt holes D13 (mm):13
Pitch circle diameter D15 (mm):216
Centre distance of the bolt holes C1 (mm):126
Rim and tyre RIMTYR:NO
One side is closed CL:NO
Weight (kg):18.6
